Control Access at Every Entry Point

Overview

Product Specifications
1. Dimensions (customizable): 1500 mm (L) × 120 mm (W) × 980 mm (H);
2. Materials: Precision die-cast aluminum alloy (top cover 10 mm thick, sides 3 mm thick) + powder-coated aluminum panel;
3. Power Supply Voltage: AC 220V ±10%, 50Hz; Drive Current >200mA;
4. Drive Motor: 24V brushless motor, 8 pairs of infrared sensors;
5. High-precision clutch mechanism, service life: 15 million cycles (with service life aging test report);
6. Operating Temperature Range: -25°C to +60°C (with high and low temperature test reports);
7. Relative humidity: ≤95%, non-condensing;
8. Input interface: 12V logic level signal or 12V pulse signal with pulse width >100ms;
9. Communication interface: RS485 electrical standard;
10. Swing door material: Acrylic/tempered glass;
11. Swing door length: ≤475mm, passage width: ≤1000mm;
12. Throughput: ≤45 people/minute;
13. Swing Arm Direction: Supports single-direction and bidirectional (optional);
14. Operating Environment: Indoor;
15. Expansion Features: Supports external integration with ID cards, IC cards, fingerprint recognition, facial recognition, finger vein recognition, QR code recognition, ID card recognition, mobile app gate opening, comprehensive anti-static equipment, security gates, visitor management systems, etc.
